10
Installation manual
5.2 Technical data
Weight, net kg
lbs
136
300
Drum volume litres
ft
3
100
3.5
Drum diameter
mm
inch
556
21 7/8
Drum speed during wash
rpm
45
Drum speed during extraction
rpm
1050
G-factor, max. 300
Heating: Electricity kW 2.0
Sound power/pressure level at extraction* dB(A) 72
Sound power/pressure level at wash* dB(A) 62
* Sound power levels measured according to ISO 60704.
5.3 Connections
Water valves DN
BSP
20
3/4”
Recommended water pressure kPa 200–600
Continuous operating pressure kPa 50–800
Capacity at 300 kPa l/min 20
Drain valve
⌀ outer mm
60
Draining capacity l/min 25
