Compact Rack Type Dishwashers
Technical data WTCS90 WTCS140 WTCS180 WTCS250
Slow speed (can be increased on-site) baskets/hr - 90 120 180
Fast speed (can be decreased on-site) baskets/hr 90 140 180 250
Length of machine (without drying) mm 1125 1125 1837 2243
Pre-wash
Pump power kW - - 0,2 1,0
Circulation l/min - - 150 300
Tank capacity l - - 45 100
Wash
Pump power kW 1 1,5 1 1,5
Circulation l/min 300 450 300 450
Tank capacity l 100 100 100 100
Rinse
Circulation l/min 4 4 4 5
Boiler capacity l 12 12 12 12
Final rinse consumption l/hr 240 240 240 300
Electrical loading
Pre-wash with optional sanitization elements kW - - 10,5 16,5
Wash tank elements kW 10,5 6 + 6 6 + 6 6 + 6
Boiler elements kW 6 + 6 6 + 6 6 + 6 10,5 + 6
Drying unit (corner and tunnel)
Heating elements kW 8,25 8,25 8,25 8,25
Fan kW 1,1 1,1 1,1 1,1
Air flow m
3
/h 1000 1000 1000 1000
Temperature °C 50 to 60 50 to 60 50 to 60 50 to 60
Transport motor kW 0,25 0,25 0,25 0,25
ESD fan kW - 0,13 0,13 0,13
Total power (without drying unit)
Min kW 13,8 14,4 14,1 19,4
Max kW 24,3 26,4 26,1 31,4
Total power (with drying unit)
Min kW 23,1 23,7 23,4 28,7
Max kW 33,6 35,7 35,4 40,7
Hot water connection °C 50 50 50 50
Cold water connection °C 15 15 15 15
Noise Level (equivalent sound pressure level) Db <70 <70 <70 <70
