A1.0 Appendix
Specifications / Features
0814131
Rev. New: 8/14/13
Models: CGR-30P and EDC-33P
CGR-30P
Weight: 1.1 Lbs.
Environmental: Designed and Tested to TSO (DO-160G)
Software: Designed and Documented to TSO (DO-178B, Level C)
Minimum Performance Standards: TSO-C43c, TSO-C44c, TSO-C45b, TSO-C47a, TSO-C48a,
TSO-49b and TSO-C55a.
Power Requirements: 7.5 to 30 Volts, 0.1 amps @ 24V (Typ), 0.2 amps @ 12 Volts (Typ).
USB Port: For USB Memory Stick use only.
Display: Active Matrix TFT, 262,144 colors, Sunlight readable
Backlight: External control line, programmable levels.
Display of Primary Gauges with Red and/or Yellow Ranges: Five on the Main Screen + EGT and CHT. One
on the Secondary Screen.
Display of Primary and Non-Primary Gauges without Red and/or Yellow Ranges: Five on the Main Screen
+ EGT and CHT. Six on the Secondary Screen.
Derived Function from Fuel Flow: Fuel Remaining, Fuel Used Since Fill-up, Fuel Used for the Flight and Time
to Empty, Fuel Remaining, Fuel Used Since Fill-up and Fuel Used for the Flight.
Derived Functions from GPS and Fuel Flow: Time to Destination, Time Reserve, Distance to Destination,
Distance to Empty, Distance Reserve, Fuel to Destination, Fuel Reserve and Economy.
Derived Functions from Internal Timer: Date, Local Time and Zulu Time.
Derived Functions from RPM: Engine Time and Tach Time, Horsepower (also required M.P.)
