25-1000-UM 14
Point List
Binary Input Points
Static (Steady-State) Object Number: 1
Change Event Object Number: 2
Request Function Codes supported: 1 (read)
Static Variation reported when variation 0 requested: 1 (Binary Input without status)
Change Event Variation reported when variation 0 requested: 2 (Binary Input Change)
Point
Index
Name/Description Change Event Class (1, 2, 3 or none)
0 High Battery Alarm (1 = Alarm) 1
1 Low Battery Alarm (1 = Alarm) 1
2 Plus Ground Fault Alarm (1 = Alarm) 1
3 Minus Ground Fault Alarm (1 = Alarm) 1
4 Ripple Voltage Alarm (1 = Alarm) 1
5 Ripple Current Alarm (1 = Alarm) 1
6 AC Power Fail Fault Alarm (1 = Alarm) 1
7 High Impedance Alarm (1 = Alarm) 1
Changes of any of these alarm states will set the class 1 data IIN bit indicating class 1 data available. If more
than 10 events occur without being read then the buffer overflow IIN bit will be set and the oldest event data
will be lost.
Analog Input Points
Static (Steady-State) Object Number: 30
Change Event Object Number: NA
Request Function Codes supported: 1 (read)
Point
Index
Name/Description Change Event Class (1, 2, 3 or none)
0 Battery Voltage (millivolts) None
1 Fault Voltage (millivolts) None
2 Minus Ground Voltage (millivolts) None
3 Ripple Voltage (millivolts) None
4 Ripple Current (millivolts) None
