8. TECHNICAL SPECIFICATION.
8.1. MEL-TEMP Features
32- bit processor.
3 capillary oven tubes up 2mm OD (storage for 1 pack
of capillary tubes).
Tube guide removal for cleaning and use of cold finger
40mm MEL-TEMP lens (magnification x 8) removable
and with ajustable focus.
13 – key membrane keypad
White 3 x Super Flux LED’s
Selectable ramp rate of 1°C/min and 10°C/min
4 x 1 Melt memory capacity
Pack of 50 capillary tubes
8.2. General specification.
Electrical specification
Total power consumption
45W
Oven control
Closed loop P.I.D.
Oven illumination
3 x white Super Flux LED’s
Illuminous Intensity (per LED)
3500 Lux
Oven operating temperature range.
Ambent +5°C to 400°C
Power supply PSU
When ordering a replacement PSU, always quote your MEL-TEMP serial number.
Input voltage
100 – 240V~50.60Hz.
Output voltage
15V DC
General specification
Temperature display range
1°C to 405°C
Display resolution
1.0°C
Accuracy
± 1% of set temperature
Ramp rate
1°C or 10°C selectable.
Display
12 x 2 backlit matrix LCD
Control Sensor
Platinum Resistance Sensor (PT100).
