Step 1 Install The Handlebar
A) Take out the bike and make it stand up.
B) Open the clip by loosing the screws on it.
C) Place the handlebar in the right position and make sure the clip is in the middle of the bar.
D) Lock the clip by tightening the screws.
Step 2 Install The Front Wheel
A) Put the bike upside down and remove the temporary protected bar by loosing the nut on it.
B) Insert the front wheel into the fork dropouts and make sure the wheel is fully seated.
C) Remove the nut and one spring on the quick release.
D) Slide the quick release through the hub from the opposite side of the brake disc.
E) Slide the spring into the hub and tighten the nut to fix the quick release.
6. Assembly
05
EN
