Electrolytic capacitor
□ 10μF (200V) 4pcs
□ 100μF (160V) 4pcs
□ 220μF (25V) 5pcs
□ 2200μF (25V) 2pcs
□ 120μF 8pcs
* The getter, the metallic silver coating inside the tube,
indicates it is a sealed vacuum tube. If this turns white, it
means that the vacuum of the tube is broken and the tube
can no longer be used.
* All vacuum tubes have been examined to ensure quality.
Some may have a minor scratch, stain, or rust-like object
that does not affect the function of the tube. Also,the
shape, heater brightness, or the printing direction vary in
each tube.
2
1. Part list
* Please check off the box in front of each item to ensure they have been included with the kit.
* There may be more screws and nuts than indicated. Keep them as spare parts.
□Knob 2pcs
(A screw for knob included)
□Power transformer 1pc
□PCB 1pc □Function label
(Silver) 1 sheet
□Insulator foot 4pcs
□Vacuum tube 12AU7(ECC82) 2pcs
A screw for knob is
included in the same
plastic bag as the
knob. Make sure to
take it out from the
plastic bag.
The pins may be bent, Adjust them to
match PCB holes before mounting
□Spark killer
(RE1201) 1pc
Screw for knob
Film capacitor
□
0.022μF (printed 223) 3pcs
□
0.033μF (printed 333) 2pcs
□ 0.1μF (printed 104) 2pcs
□ 0.47μF (printed 474) 4pcs
□Zener diode
(made of glass) 3pcs
□Bridge diode
(printed ～,＋,and－) 6pcs
□FET 02N60Z
1pc
□LED 1pc
□Tube socket
(9-pin) 2pcs
□AC inlet
1pc
□Flange bushing
2pcs
□Ceramic coupling
2pcs
□Vinyl tube 1pc
Metal shaft
□Long (φ6x150mm) 2pcs
□Short (φ3x25mm) 2pcs
Connector
□2-pin 2pcs
□4-pin 1pc
□7-pin 1pc
□AC power cord 1pc
□Connector cable 1pc
□Midget fuse
(0.5A 250V)
1pc
□Fuse holder 2pcs
□Pin jack
(RCA jack)
5pcs
□4-pole mini jack
1pc
□Relay 1pc
□Toggle switch
（with a nut and a washer)
1pc
□Volume
(50kΩA, Dual) 1pc
(With a nut and a washer)
Binding screw
□Small(M3x8) 23pcs
□Large(M4x8) 4pcs
□Hex screw spacer 5pcs
(Hex, M3x17 female-female)
□Rotary switch 1pc
(With a nut and a washer)
□Push switch
2pcs
□Binding tapping screw
(M3x10) 5pcs
□Finger screw
(M3x8) 1pc
□Nut (M3)
1pc
□Claw washer (M3) 7pcs
□PCB terminal
3pcs
□Masking felt
(Black) 1pc
□LED mask
(Opaque white) 1pc
□PTC (Mustard) 1pc
□IC socket
(8-pin) 2pcs
IC
□LM2940CT-12 1pc
□LM2990T-12 1pc
□2068DD 2pcs
□
40106B (or 4584B)
1pc
□4040B 1pc
Cement resistor(5W)
□15Ω (printed 15Ω
or 150 or15R) 1pc
Metal-film resistor(1/4W)
□
100Ω (BRN-BLK-BLK-BLK-GLD) 6pcs
□
390Ω (ORN-WHT-BLK-BLK-BRN) 4pcs
□
3.3kΩ (ORN-ORN-BLK-BRN-BRN) 4pcs
□
10kΩ (BRN-BLK-BLK-RED-BRN) 5pcs
□
33kΩ (ORN-ORN-BLK-RED-BRN) 4pcs
□
100kΩ (BRN-BLK-BLK-ORN-BRN) 19pcs
□
470kΩ (YEL-VIO-BLK-ORN-BRN) 18pcs
Resistor(1/4W)
□
2.2Ω (RED-RED-GLD-GLD) 3pcs
□
3.3MΩ (ORN-ORN-GRN-GLD) 2pcs
* Top and bottom chassis and
the front panel are temporarily
fixed with screws.
□Front panel 1pc
□Bottom chassis 1pc
□Top chassis
1pc
Some units may be already
separated from the PCB
at the perforated line.
□Warning label
(yellow) 1pc
Resistor
(20V,Low-ESR)
Color indication
To Next Page
