Betriebs- und Montageanleitung ND
*1)
min. value / max. value of characteristic curve
*2)
A-side / B-side standard designation
*3)
NEMA Premium
*1)
min. Wert / max. Wert der Kennlinie
*2)
A-seitig / B-seitig Normbezeichnung
*3)
NEMA Premium
D 064
IE3 27,0 1050 3000 2910 230/400 50 4,20/2,40 1,10 - 15 73 / 81
6204IE3 32,0 1550 3600 3490 230/400 60 4,55/2,65 1,32 - 17 78 / 84
NEMA
*3)
32,0 1550 3600 3490 277/480 60 3,80/2,20 1,32 - 17 78 / 84
E 064
- 28,0 1000 3000 2800 230 50 6,7 1,10 30/450 17 73 / 81
6204
- 26,0 1500 3600 3360 230 60 6,7 1,10 30/450 17 78 / 84
D 066
IE3 38,0 1200 3000 2905 230/400 50 5,40/3,10 1,50 - 21,5 74 / 86
6205IE3 38,0 1300 3600 3505 230/400 60 6,40/3,70 1,80 - 21,5 74 / 86
NEMA
*3)
38,0 1300 3600 3505 277/480 60 5,40/3,10 1,80 - 21,5 74 / 86
E 066 - 36,0 1200 3000 2880 230 50 9,5 1,50 30/450 18 74 / 86 6205 D 07
IE3 41,0 1200 3000 2870 230/400 50 7,60/4,40 2,20 - 25 76 / 81
6205IE3 41,0 1600 3600 3480 230/400 60 9,10/5,30 2,64 - 25 81 / 85
NEMA
*3)
41,0 1600 3600 3480 277/480 60 7,60/4,40 2,64 - 25 81 / 85
D 072
IE3 52,0 1200 3000 2900 230/400 50 10,2/5,90 3,00 - 27 76 / 86
6206IE3 52,0 1600 3600 3500 230/400 60 12,4/7,10 3,60 - 27 81 / 89
NEMA
*3)
52,0 1600 3600 3500 277/480 60 10,3/6,00 3,60 - 27 81 / 89
D 08
IE3 50,0 1700 3000 2870 230/400 50 7,60/4,40 2,20 - 30 79 / 84
6206IE3 42,0 2300 3600 3480 230/400 60 9,10/5,30 2,64 - 30 86 / 88
NEMA
*3)
42,0 2300 3600 3480 277/480 60 7,60/4,40 2,64 - 30 86 / 88
D 082
IE3 60,0 1700 3000 2900 230/400 50 10,2/5,90 3,00 - 33 79 / 86
6206IE3 53,0 2300 3600 3500 230/400 60 12,4/7,10 3,60 - 33 86 / 89
NEMA
*3)
53,0 2300 3600 3500 277/480 60 10,3/6,00 3,60 - 33 86 / 89
D 09
IE3 80,0 1900 3000 2940 400
 50 10,2 5,50 - 66 87 / 95
6308IE3 80,0 2700 3600 3540 400
 60 12,4 6,60 - 66 91 / 99
NEMA
*3)
80,0 2700 3600 3540 480  60 10,3 6,60 - 66 91 / 99
D 092
IE3 95,0 1900 3000 2935 400
 50 13,4 7,50 - 71 87 / 99
6308IE3 91,0 2700 3600 3535 400
 60 16,1 9,00 - 71 91 / 102
NEMA
*3)
91,0 2700 3600 3535 480  60 13,4 9,00 - 71 91 / 102
