ELEMENT Central Vacuum Systems
8
EMPTYING THE DIRT CANISTER & FILTER
MAINTENANCE
For Inverted Bag Models: 1300, 1700 & 2300
The dirt canister is the removable lower portion of the power unit.
Follow These Steps (Refer to figures 1-4)
Make sure the power unit is OFF.
FIG. 3
FIG. 1
FIG. 4
FIG. 2
1. Unlatch and remove the dirt canister. Latches are located on opposite
sides of the power unit. When the dirt canister is removed the
permanent inverted filter will be visible. (Fig. 1)
2. Hold a large disposable bag around the bottom portion of the power
unit. (Fig. 2)
3. Take hold of the sewn-in weight located at the bottom of the permanent
filter, now inside the disposable bag and shake the weight. NOTE:
Shaking the weight of the permanent filter will be sufficient for
cleaning. DO NOT vacuum, brush or scrape the filter as it will cause
damage. (Fig. 3)
4. Carefully remove the disposable bag and empty the dirt and debris in
the dirt canister into the bag, close and dispose of.
5. Raise the dirt canister to the base of the power unit and engage the
latches. Be certain the dirt canister is seated properly to the gasket on
the base of the power unit. (Fig. 4)
8
