Elemental Machines Element-A User Manual

Element-A, EA2 User Manual
www.elementalmachines.io
sales@elementalmachines.io
771-00008 rev 02 Element-A, EA2 User Manual
Copyright © 2020 Elemental Machines
Page 13 of 15
Specifications
Element-A Specifications
Model Number
EA2
Dimensions
2.5”x2.5”x0.8”
Operating Temperature Range
-10 – 45C
Operating Humidity Range
0 – 95% RH, Non-condensing
Operating Pressure Range
300 – 1100hPa
Battery Life
5 Year (3 Year Typical)
Sensor Specifications
Temperature Range
-10 – 45C
Temperature Accuracy*
Typical +/- 0.2C, Max +/- 0.5C, Drift: <0.03 degrees
C/yr
Humidity Range
0 – 95% RH, Non-condensing
Humidity Accuracy*
0% to 80% RH Typical ±2.0% RH, Max ±3.0%
80% to 95% RH *Typical ±3.0% RH, Max ±5.0%
Drift: typical <0.25%/yr max of <0.5%/yr**
Pressu
re Range
300 – 1100hPa
Pressure Accuracy*
±1.0 hPa from 0C to 60C, ±1.7 hPa from -10C to 0C
Light Range
For light and dark cycle tracking only
*Temperature, pressure, and humidity are factory calibrated to a NIST traceable standard
**
Extended
exposure to high humidity and high temperature may cause an accrued RH offset
Communication
Data Sampling and
Transmission Rate
15 Seconds
Protocol (Element)
Bluetooth® Low Energy 4.1
Range
30 Meters
Frequency band (power)
2.4 GHz (4.8 dBm ≡ 3mW)
Compliance
FCC ID
TFB-1005, FCC Part 15.247
IC ID
5969A-1005, RSS 247
CE
2011/65/EU and amendment 2015/863
(RoHS)
EN 63000
2006/66/EC and amendment 2013/56/EU
(Batteries Directive)
EN 50419, EN 63000
2012/19/EU (WEEE)
EN 50419
2014/53/EU (RED)
ETSI EN 300 328
safety under 2014/3
5
/EU (LVD)
EN61010-1, EN 62311
And essential EMC reqs under
2014/30/EU
ETSI EN 301 489-1, EN 61000-4-2, EN 61000-4-3,
EN 55011
Giteki
Compliant to standard ARIB STD-T66 v3.7
201-170613 (PCB trace antenna)
RCM
Compliant to standard AS/NZS 4268:2017
