50
Lever Controller Assembly
10
5
Push G19 To The Bottom
1
2
G19
G19
C1
P2
E29
P5
G19
PUSHPUSHPUSHPUSH
1:1
Very Important ! P5 (Brake Pad) must be clean and not stained by oil.
Make sure to hand clean and dry P5 before assembly.
