-5-
PARTS LIST
Qty. Description Part #
RESISTORS
1 .18W 3W 101804
2 2.7W 1/2W (red-violet-gold-gold) 112701
2 180W 1/4W (brn-gray-brn-gold) 131800
22kW Potentiometer 192422
CAPACITORS
510mF Electrolytic 271045
2 2,200mF Electrolytic 292226
1 4,700mF Electrolytic 294744
SEMICONDUCTORS
4 1N4001 Diode 314001
4 1N5400 Diode 315400
1 MPSA70 Transistor 320070
1 2N6124 Transistor 326124
1 LM-317 IC 330317
1 LM-337 IC 330337
1 LM-7805 IC 337805
MISCELLANEOUS
1 Transformer 440720
1 PC Board 512013
1 Fuse 1.25A 530125
1 Rocker Switch 541204
1 Cover 611120
1 Chassis 612020
1 Heat Sink 615010
Qty. Description Part #
2 Knob 622009
1 Strain Relief 624003
5 Bushing 624007
4 PC Board Stand-off 625001
2 Black Binding Post 625031
5 Lockwasher 625031LW
5 Nut 625031HN
2 Red Binding Post 625032
1 Yellow Binding Post 625034
1 Cable Ties 628982
5 Screw 6-32 x 3/8” 641640
2 Screw 8-32 x 3/8” 641840
4 Screw 6 x 3/8” black 642652
2 Screw 6 x 3/8” black 642660
2 Nut 7mm 644101
1 Nut 6-32 644600
4 Nut 6-32 small 644601
2 Nut 8-32 644800
2 Flat Washer 8mm x 14mm 645101
2 Lockwasher 5/16” 646101
3 Lockwasher #8 646828
4 Rubber Feet 662003
1 Fuse Holder (lower body) 663005LB
1 Fuse Holder (nut) 663005N
1 Fuse Holder (upper body) 663005UB
1 Fuse Holder (washer) 663005W
3 Mica Insulator 780002
1 Line Cord 862105
