elepho eClear - Technical Data and Parts Identification; Parts Identification; Display Indicators

6
5. Technical Data
6. Parts identification
6.1 Parts
6.2 Display
Name Nasal Aspirator (eClear)
Model HTD2601US
Display LED
Operating conditions
Ambient temperature:
41˚F - 113˚F (5˚C - 45˚C)
Relative humidity (RH): ≤85%
Atmospheric pressure: 700 hPa-1060 hPa
Transport and storage
conditions
Ambient temperature: -
4˚F - 131˚F (-20˚C - 55˚C)
Relative humidity (RH): ≤93%
Atmospheric pressure: 700 hPa-1060 hPa
Product weight: 5.9oz (167g)
Suction range: ≤ 65kpa
Automatic Power-off ≤ 65 s
Internal power supply Lithium Polymer Battery: DC 3.7V
USB Power Source Input: DC 5V, ≥1A
1. Suction nozzle
2. Transparent cover
3. Collecting cup base
4. Display screen
5. Power button
6. Plastic shell
7. USB charging interface
8. Induction electrode
9. Collecting cup
10. Air inlet of pump body
1. Cleaning prompt
2. Battery capacity indicator
3. Suction level indicator
1
2
3
4
5
6
1
3
7
8
10
2
9
