STEP 4 Cable Management
For both bottom and upper portion of the spring arm, just slide the cable cover up and away
from the spring arm, do not need to take much effort to pull the ends of the cable cover
away from the spring arm.
On the bottom portion of the spring arm, insert the cable and slide the cable cover down;
On the upper portion of the spring arm, press the tabs on the inside of the cable cover
slightly inward and slide down to reattach the cable cover.
1
2
