STORAGE FEATURE
Spin the L pin 90 degrees and then pull out from the center hole. Fold the main vertical arm to the
horizontal position (down on the opposite side of folding shank) and re-secure using the L pin or by
folding the horizontal arms upward.
Fold the vertical arms to the horizontal position and then fold the folding shank assembly to the
vertical position.
FOLDING THE CARRIER
