screw
plinth
screw
1
Unscrew the tw screws and remove the plinth from the dishwasher. [Figure a]o
2
Unscrew adjust the distance of left and right plinth tab to your need.
The adjustable range is from 39mm to 134mm. [Figure b]
the two screws and
●
Installation the plinth
3
Fix the plinth on the plinth tab. According to your need to adjust the plinth height, the
adjustable range is from 56mm to 122mm. [Figure c]
[Figure a]
[Figure b]
[Figure c]
plinth
plinth tab
20
