Connect the cold water supply hose to a threaded 3/4(inch) connector and make sure that it is
fastened tightly in place.
If the water pipes are new or have not been used for an extended period of time, let the water run to
make sure that the water is clear and free of impurities. If this precaution isnottaken,thereisarisk
that the water inlet can get blocked and damage the appliance.
The water supply to the appliance can also be connected to the house hot water line (centralized
system, heating system),as long as it does not exceed a temperature of 60 C.In this case, the wash
cycle time will be shortened by about 15 minutes and the wash efficiency slightly reduced.
Theconnection must be made to thehot water linefollowing the same procedures as those for the
connection to the cold water line.
In order to avoid that there is more water staying in the inlet hose,
please close the hydrant after using.(For the models: no safety inlet hose.)
Positioning the Appliance
Position the appliance in the desired location. The back should rest against the wall behind it,
and the sides, along the adjacent cabinets or wall. The dishwasher is equipped with water supply
and drain hoses that can be positioned to the right or the left to facilitate proper installation.
Levelling the Appliance
Check
Front
to Back
Level
Check level
side to side
Once the appliance is positioned, adjust
thefeet(screwingtheminorout)toadjust
the height of the dishwasher, making it level
Inanycase,theapplianceshouldnotbe
inclined more than 2 .
NOTE:
The maximum adjustment height of the feet
is 20 mm.
22
Insert the drain hose into a drain pipe with a minimum diameter of 40 mm, or let it run into the sink, making sure to avoid bending
or crimping it. Use the special plastic support that comes with the appliance. The free end of the hose must be at a height
between 400 and 1000mm and must not be immersed in water.
FRONT VIEW
Inlet pipe connector Drain pipe connector
P
O
W
E
R
O
U
T
L
E
T
SINK
DISHWASHER
Min 100mm
