Elgo LIMAX33CP - Table of Contents; Contents; Kit Components

- 2 -
1 Contents
1 Contents ............................................................................................................................ 2
2 Kit Components ................................................................................................................ 2
3 About this Document ........................................................................................................ 3
4 Installation Procedure ...................................................................................................... 4
5 Magnetic Tape Cleaning ................................................................................................. 12
2 Kit Components
Kit Components
Crossbeam (2x)
Crossbeam for safety position detector (1x)
Tape fixture for position detector (1x)
Tape fixture (1x)
Spring (1x)
Cable ties (2x)
Rail clips including screws and nuts (6x)
Position detector including screws and cable gland (1x)
Original description of position detector
Magnetic Tape AB20-80-10-1-R-D-15-BK80
LIMAX33 CP
LIMAX33 CP Mounting angle set
Magnetic Tape AB20-80-10-1-R-D-15-BK80
LIMAX33 CP
LIMAX33 CP Mounting Angle
Mounting angle for LIMAX33 CP
with four each of screws, nuts
and washers for mounting
the sensor.
1
2
3
4
5
6
7
8
9
10
11
10
11
9
8
7
6
4
2
3
5
1
NOTE!
The arrows on the
magnetic tape and the
sensor must always
point upwards towards
the shaft head!
NOTE!
The arrows on the magnetic
tape and the sensor must
always point upwards towards
the shaft head!
