DMX TRAITS
CHANNEL
DMX
VALUES
FUNCTION
6CH 7CH 8CH 11CH 12CH
1 1 1 1 1 000 - 255 Red, 0% to 100%
2 2 2 2 2 000 - 255 Green, 0% to 100%
3 3 3 3 3 000 - 255 Blue, 0% to 100%
4 4 4 4 4 000 - 255 White, 0% to 100%
5 5 5 5 5 000 - 255 Amber, 0% to 100%
6 6 6 6 6 000 - 255 UV, 0% to 100%
7 7 7 7 000 - 255 Master Dimmer, 0% to 100%
8 8 8
Strobing
000 - 031 LED Off
032 - 063 LED On
064 - 095 Strobing, slow to fast
096 - 127 LED On
128 - 159 Pulse Strobing, slow to fast
160 - 191 LED On
192 - 223 Random Strobing, slow to fast
224 - 255 LED On
9 9
Program Selection Mode
000 - 051 Dimming Mode
052 - 102 Color Macro Mode
103 - 153 Color Change Mode
154 - 204 Color Fade Mode
205 - 255 Sound Active Mode
10 10
Color Macros/Programs
000 - 255
Color Macro Mode, see Color Macro
Chart section of this manual
Color Change Programs
000 - 015 Color Change 1
016 - 031 Color Change 2
032 - 047 Color Change 3
048 - 063 Color Change 4
064 - 079 Color Change 5
080 - 095 Color Change 6
096 - 111 Color Change 7
112 - 127 Color Change 8
128 - 143 Color Change 9
144 - 159 Color Change 10
160 - 175 Color Change 11
176 - 191 Color Change 12
192 - 207 Color Change 13
208 - 223 Color Change 14
224 - 239 Color Change 15
240 - 255 Color Change 16
