DMX TRAITS
NOTES:
11Ch Mode:
• When Channel 9 is between the values of 0-51, Channels 1-6 are used, and Channel 8 will control
strobing.
• When Channel 9 is between the values of 52-102, Channel 10 is in Color Macros Mode, and Channel
8 will control strobing.
• When Channel 9 is between the values of 103-153, Channel 10 is in Color Change Mode, and
Channel 11 will control the color change speed.
• When Channel 9 is between the values of 154-204, Channel 10 is in Color Fade Mode, and Channel
11 will control the color fade speed.
• When Channel 9 is between the values of 205-255, Channel 10 is in Sound Active Mode, and
Channel 11 will control the sound sensitivity.
12Ch Mode:
• When Channel 9 is between the values of 0-51, Channels 1-6 are used, and Channel 8 will control
strobing.
• When Channel 9 is between the values of 52-102, Channel 10 is in Color Macros Mode, and Channel
8 will control strobing.
• When Channel 9 is between the values of 103-153, Channel 10 is in Color Change Mode, and
Channel 11 will control the color change speed.
• When Channel 9 is between the values of 154-204, Channel 10 is in Color Fade Mode, and Channel
11 will control the color fade speed.
• When Channel 9 is between the values of 205-255, Channel 10 is in Sound Active Mode, and
Channel 11 will control the sound sensitivity.
CHANNEL
DMX
VALUES
FUNCTION
6CH 7CH 8CH 11CH 12CH
11 11
Program Speed / Sound Sensitivity
000 - 255 Program Speed, slow to fast
000 - 255
Sound Sensitivity, least to most
sensitive
12
Dimmer Curves
000 - 020 Standard
021 - 040 Stage
041 - 060 TV
061 - 080 Architectural
081 - 100 Theatre
101 - 255 Default to factory settings
