DMX TRAITS
Eliminator Mini Par Bar - DMX Traits
Software Version 1.0
CHANNEL DMX VALUE DESCRIPTION
1
Mode
000 - 010 No function
011 - 050 Macro A1: Macro color
051 - 100 Macro A2: 18 color change
101 - 150 Macro A3: Fade mode
151 - 200 Macro A4: Sound active mode
201 - 255 Macro A5: Strobe mode
2
(CH1 = 011 -
050)
Color Macro
000 - 039 RGBW, all on
040 - 049 Red
050 - 059 Green
060 - 069 Blue
070 - 079 Yellow (RG)
080 - 089 Cyan (GB)
090 - 099 Purple (RB)
100 - 109 White
110 - 119 Orange (RG)
120 - 129 Pink (RB)
130 - 139 RW
140 - 149 GB
150 - 159 GW
160 - 169 BW
170 - 179 RGW
180 - 189 RBW
190 - 199 GBW
200 - 209 RGB
210 - 255 RGBW (all on)
CONTINUED ON NEXT PAGE
22
