Rev111010-ESC
www.elitescreens.com
14. Be sure to turn the end
cap at a 45 degree radius
upwards when replacing it so
that the motor peg can insert
back into the cap to allow the
cap to seal back in to its place.
12. Put metal box cover back
in to place and tighten with
the screw and nut.
13. For easier access, place a
small platform (like a piece of
Styrofoam) under the screen
so that it is elevated about a
few inches. Check to be sure
that the limit switches are
facing the right direction as
shown in this picture and that
the wires are snugly put back
in to the screen’s casing so
that the end cap cover can be
easily replaced.
