Elite Screens Kestrel Series User Manual

5
Kestrel Tension Series Dimensions Table
Unit: mm
Model
Diagonal
Size/Aspect
Ratio
Case
Length
(A)
Top
panel
Length
(A1)
Screen
Width
(A2)
View
Width
(A3)
L/R Black
Masking
Border
(A4)
Top
black
drop
(B3)
Screen
Material to
Bottom
Bar (B1)
View
Height
(B2)
Screen
Overall
Height
(B)
Bottom
black
drop (B4)
N.W.
(KGS)
FTE84V
84" (4:3)
2021.0
1989.0
1858.9
1706.9
76
76
2134.2
1280.2
2244.2
762.0
22.3
FTE92V
92" (4:3)
2174.0
2142.0
2021.4
1869.4
76
76
2103.7
1402.1
2213.7
609.6
23.9
FTE84H
84" (16:9)
2174.0
2142.0
2011.6
1859.6
76
76
1950.9
1046.1
2060.9
812.8
23.9
FTE92H
92" (16:9)
2352.0
2320.0
2188.8
2036.8
76
76
1999.7
1145.7
2109.7
762.0
25.9
FTE85C
85" (2.35:1)
2302.0
2270.0
2498.5
2346.5
76
76
1750.0
845.2
1860.0
812.8
23.0
FTE92C
92" (2.35:1)
2465.0
2433.0
2302.1
2150.1
76
76
1819.7
914.9
1929.7
812.8
24.7
FTE96C
96" (2.35:1)
2558.0
2526.0
2395.6
2243.6
76
76
1859.4
954.6
1969.4
812.8
25.6
FTE103C
103" (2.35:1)
2722.0
2690.0
2559.2
2407.2
76
76
1929.0
1024.2
2039.0
812.8
27.2
Unit: Inch
Model
Diagonal
Size/Aspect
Ratio
Case
Length
(A)
Top
panel
Length
(A1)
Screen
Width
(A2)
View
Width
(A3)
L/R Black
Masking
Border
(A4)
Top
black
drop
(B3)
Screen
Material to
Bottom
Bar (B1)
View
Height
(B2)
Screen
Overall
Height
(B)
Bottom
black
drop (B4)
N.W.
(LBS)
FTE84V
84" (4:3)
79.6
78.3
73.2
67.2
3.0
3.0
84.0
50.4
88.4
30.0
49.1
FTE92V
92" (4:3)
85.6
84.3
79.6
73.6
3.0
3.0
82.8
55.2
87.2
24.0
52.6
FTE84H
84" (16:9)
85.6
84.3
79.2
73.2
3.0
3.0
76.8
41.2
81.1
32.0
52.6
FTE92H
92" (16:9)
92.6
91.3
86.2
80.2
3.0
3.0
78.7
45.1
83.1
30.0
57.0
FTE85C
85" (2.35:1)
90.6
89.4
98.4
92.4
3.0
3.0
68.9
33.3
73.2
32.0
50.6
FTE92C
92" (2.35:1)
97.0
95.8
90.6
84.6
3.0
3.0
71.6
36.0
76.0
32.0
54.2
FTE96C
96" (2.35:1)
100.7
99.4
94.3
88.3
3.0
3.0
73.2
37.6
77.5
32.0
56.3
FTE103C
103" (2.35:1)
107.2
105.9
100.8
94.8
3.0
3.0
75.9
40.3
80.3
32.0
59.9
*Measurement dimensions are intended as a reference only and subject to change without notice. Note：Data Error may be ±1"
