Elite ARC 130XP - MMA Process Electrode Diameter and Hot Start Adjustment; MMA Electrode Diameter Adjustment; MMA Hot Start Percentage Adjustment

KEEP WORKiNG
Keep Working
KEEP WORKiNG
17
Si6130XP Si7160XP
Si7175XP Si7200XP
in
in
in
in
To adjust the Hot Start percentage press the knob until
the icon has the white arrow below it.
To adjust the electrode diameter, press the knob until the
icon has the white arrow below it.
By adjusting the electrode diameter, the equipment will automatically adjust the recommended output current for this
electrode and also select the base material thicknesses that can be welded with the selected electrode diameter, the
material thicknesses that exceed the capacity of the electrode will not will appear in the material thickness adjustment
menu.
Hot Start is a technology that facilitates the starting of the arc, momentarily increasing the current when starting the
arc. You can adjust the value from 100% to 150%.
Turn the knob to set the diameter of the electrode to be
used and press the knob to save.
Turn the knob to set the diameter of the electrode to be
used and press the knob to save.
