1. Product description
1.1 General
ELITE ARC series welding machines are converter type Manual Metal Arc Welding Machines
using stick electrode. They intend to be connected to 95-270V 50-60Hz single-phase supply
mains. All of the ELITE ARC models are equipped with output regulating circuit, which enable a
continuous adjustment of the welding output.
1.2 Model description
The ELITE ARC Sereis, are designed for a professional use, delivering the best ARC
performance even on CEL electrodes.
Model
Overall Dimension (mm)
Weight (kg)
ELITE ARC 180
390x150x270
6.5 Kg
ELITE ARC 220
390x150x270
7.5 Kg
1.3 Parameter
All ELITE ARC series welding machines are with drooping external static characteristic. They
have welding capacity up to 180A/220A. Markings are shown below.
1.4 Symbol specification
U
0
Rated no-load voltage
U
1
Rated supply voltage
U
2
Conventional output voltage
I
2
Conventional welding current
X
Rated duty cycle
1
I
1max
Rated maximum supply current
I
1eff
Maximum effective supply current
Single phase, 50 / 60 Hz main supply
