3
Contents & Components
Accessories:
45 Degree Elbow
Use to de-stress the hose at the weir•
Please note:
No guarantee is given on vinyl liners when used with a Elite Pool
Cleaner
Discoloration of pool cleaner parts are normal due to pool chemicals,
this does not influence the performance or the life of the components
•
•
Swivel Nut
Hose
Swivel
Swivel
Insert
Main Body
Bump Strip
Clip-on
Weight
Ballast
Weight
Hammer
(Flapper)
Hammer
(Flapper)
Cover
Foot Pad
Skirt
/Seal/Disc
Pool Hose
Weir adaptor
(Australia only)
45° elbow
(Australia only)
Flo n Show
weir valve
Weir
adaptor
45° elbow
Defelctor
Assembly
(Australia
Only)
Slip
Washer
Contents & Components 3
Pre-installation Checklist 4
Pre-installation Check list 5
The Poolmaid Weir Valve 6
Trouble Shooting 7
Trouble Shooting continued 8
Connection to Skimmer Points (Only Australia) 8
