4A-4
01
A
Install wall plate using lag
bolts and washers B .
Tighten the lag bolts until
they are pulled firmly against the
wall plate .
01
- 8 -
01
Position the wall plate at
your desired height , level
the wall plate and mark the
pilot hole locations x4.
Drill pilot
holes
4B-2
4B-1
2.75in 70 mm
Ø 10 mm
Ø 10 mm
A
B
01
01
A
B
UP
For concrete wall installations ONLY
CAUTION:Do not use in drywall or wood
No!
2
STEP 4B Wall Plate Installation (Concrete or Brick)
