Elived EV011 - Page 8

Secure TV with brackets against the
horizontal plate with the pre-assembled
screws
Preassembled
screw
- 8 -
2B-3
A
B
D
Concrete Wall
Concrete Wall
STEP 3 Lift and hang TV with brackets onto wall bracket.
01
A
B
01
Install wall plate using lag bolts ,
washer and anchor (not included).
Tighten the lag bolts until they are
pulled firmly against the wall plate .
A
01
No!
02
01
