Parts and Hardware
WARNING:
This product contains small items that could be a choking hazard if
swallowed. Before starting assembly, verify all parts are included and undamaged. For parts
shortage or damage, please contact us.
NOTE: Not all hardware included will be used.
TV Brackets
M8
M6
M4
1-1 Select TV Screws
1-2 Need Spacer?
x4
x4 x4
x4
x4
x4
x8
x4
x8
Philips Screws
TV Screws / Spacers / Washers
Philips Screws
Philips Screws Spacers
Washers
Spacers
M4 x 12mm
M4 x 30mm
M6 x 15mm
M6 x 30mm M8 x 45mm
M8 x 25mm
M6 M8 x 5mm
M-A
M-B M-C M-D M-E M-F
M8 x 10mm
- 3 -
x1
A
x1
B
TV back
Bracket
Washer
Bracket
Long Screw
Spacer
No, just choose the screws, washers.
Yes, choose the appropriate screws, washers,
and spacers for your TV.
TV back
Short Screw
Washer
Highly recommended to add spacers for more
spacing between bracket and TV.
To Next Page
