STEP 2B Wall Plate Installation (Concrete or Brick)
Drill pilot
holes
2.75in 70 mm
Ø 10 mm
Ø 10 mm
2A-4
2B-1
2B-2
01
01
2
01
A
B
01
Install wall plate using lag bolts
and washer . Tighten the lag bolts
until until they are pulled firmly against
the wall plate .
A
B
A
01
Position the
wall plate
at your
desired
height , level
the wall plate
and mark the
polit hole
locations.
