Concrete Wall
Concrete Wall
01
A
B
01
Install wall plate using lag bolts ,
washer and anchor (not included).
Tighten the lag bolts until they are
pulled firmly against the wall plate .
A
01
STEP 3
Lift and hang TV with brackets [02] onto wall bracket [01].
02
02
01
01
Secure TV with brackets against the
horizontal plate with the pre-assembled
screws
Preassembled
screw
- 8 -
Contact us by email help@elivedglobal.com to have
these additional pieces shipped directly to you.
Concrete Wall Anchor
4pcs
Concrete wall anchor (NOT INCLUDED)
A
B
