Elived YD1001 - Page 9

± 3°
Adjustments
± 3°
Tilting angle adjustment (+5° / -10°)
Pull TV to your desired angle then fasten tilting nuts with
open end wrench.
Leveling adjustment (-3°/+3°)
If needed, TV can be leveled ±3 degrees via adjusting the 4 nuts
with the open end wrench.
- 9 -
