Installation manual Laser scanne
D-ID: V1_3 – 06.19 Changes can be made without further notification! 13
When mounting the laser scanner, ensure the correct positioning inside of the additional housing. The
viewing window and the detection field of the laser scanner must not be reduced by using the
additional housing or any other (on-site) covers.
Mounting bracket laser scanner A:
Drawing 9
The assembly takes place without additional cable protection. The lead of the laser scanner is inserted
directly into the barrier housing.
Mounting bracket laser scanner B:
When a second laser scanner is used, it must be mounted mirror-inverted to the first laser scanner on
the other side of the housing.
