Page 5 1000004299 (Rev. B - 04/2018)
LVRC8WS_2AWR, LVRCWS_2AWR
Operation: Start-Up
Exposed electrically energized components. Use extreme caution.
Operation: Bottle Filler Control Board Set-Up
VERIFY CONTROL BOARD SOFTWARE
To verify the software program of the control board the unit
will need to be shut down and restarted. The chiller (if pres-
ent) does not need to be shut down and restarted.
The unit’s lower panel must be open to access the power
cord and wall outlet.
Shut down the unit by unplugging the power cord from the
wall outlet or switching off the circuit breaker to the unit.
Restart the unit by plugging the power cord back into the wall
outlet or by switching on the circuit breaker to the unit.
Upon start up, the bottle count display will show the software
designation of BF11 or BF12.
ACCESSING THE PROGRAMMING BUTTON
To access the program button, remove the top cover of the
bottle ller. Remove the two (2) screws holding top cover to
bottle-ller with a 5/32” allen wrench. Remove top cover. Do
not discard mounting screws, they will be needed to reinstall
the top cover after programming operations are completed.
The programming button is located at the top right side of
the unit on the control board.
RESET THE FILTER MONITOR
Instructions apply to ltered units only.
Depress the program button for approximately 2 seconds un-
til the display changes then release. The display will change
and scroll through two messages:
“RST FLTR” – Reset Filter Monitor
“SETTINGS” – System Settings Sub Menu
If the program button is not pushed again the display will
scroll through the two messages above for three cycles and
then de-fault back to bottle count and be back in run mode.
When the display changes to “RST FLTR”, depress the
button again. The display will change to show “FLTR =”. De-
press the button again and the display will show “FLTR =0”
The Green LED should be illuminated indicating that the
visual lter monitor has been reset.
SETTING RANGE OF THE IR SENSOR
Depress the program button for approximately 2 seconds un-
til the display changes then release. The display will change
and scroll through two messages:
“RST FLTR” – Reset Filter Status LED
“SETTINGS” – System Settings Sub Menu
If the program button is not pushed again the display will
scroll through the two messages above for three cycles and
then default back to bottle count and be back in run mode.
When the display changes to “SETTINGS”, depress the but-
ton again. The display will change to show
“RNG SET” - Range set for IR sensor.
When the display changes to “SETTINGS”, depress the button again.
The display will change to show
“RNG SET” - Range set for IR sensor.
“UNIT TYP” - Type of unit (REFRIG or NON-RFRG)
“FLT SIZE” - Select lter capacity.
“RST BCNT” - Reset bottle count
When display shows “UNIT TYPE” push program button once the dis-
play will show current value. Can be REFRIG or NON-RFRG
Push button once to change value. Once value is selected the display
will show the new value. (Can be REFRIG or NON-RFRG)
“REFRIG“- stands for refrigerated product. In this setting the ow rate is
estimated at 1.0 gallon per minute.
“NON-RFRG“- stands for nonrefrigerated product. In this setting the ow
rate is estimated at 1.5 gallons per minute. Both “REFRIG“ and “NON-
RFRG“ simulate 1 bottle equal to 20 oz.
Allow approximately 4 seconds to pass and the display will return to
bottle counter and be in run mode.
RESETTING BOTTLE COUNT
Depress the program button for approximately 2 seconds until the
display changes then release. The display will change and scroll through
two messages:
“RST FLTR” – Reset Filter Status LED
“SETTINGS” – System Settings Sub Menu
If the program button is not pushed again the display will scroll through
the two messages above for three cycles and then default back to bottle
count and be back in run mode.
When the display changes to “SETTINGS”, depress the button again.
The display will change to show:
“RNG SET”- Range set for IR sensor.
“UNIT TYP” - Type of unit (REFRIG or NON-RFRG)
“FLT SIZE” - Select lter capacity
“RST BCNT” - Reset bottle count
If the button is not pushed again the display will scroll through the four
messages above for three cycles and return to run mode.
When display shows “RST BCNT” push program button once the display
will show current value e.g. “0033183”.
Once display shows current value push the program button once more
to reset back to 0. The display will show BTLCT = 0 for approximately 2
seconds and then return to run mode showing 00000000 bottles. NOTE:
Once the bottle count is reset to zero there is no way to
return to the previous bottle count.
Testing the bottle counter:
REFRIG units: Place bottle or hand in front of sensor for 9.4 sec-onds
to see bottle counter count 00000001, (This is based on lling a 20 oz.
bottle)
NON-RFRG units: Place bottle or hand in front of sensor for 6.25 sec-
onds to see bottle counter count 00000001, (This is based on lling a 20
oz bottle)
1.
3.
2.
5.
4.
1.
1.
2.
6.
2.
4.
3.
5.
7.
2.
1.
Continued from below:
3.
4.
1.
2.
3.
4.
5.
6.
7.
1. Turn water supply on and inspect for leaks. Fix all leaks before continuing.
2. Connect plug-end of International Power Cord Sets from the Cooler and Bottle Filler into electrical outlets. Bottle Filler must have electrical
power to dispense water. Be sure to reinstall fuse to the circuit or switch the circuit breaker back to the “ON” position.
WARNING
4. The GREEN LED light on the Bottle Filler should illuminate showing good lter status along with the LCD Bottle Counter.
5. Recheck all water and drain connections with water owing through system. Fix all leaks before continuing.
6. Once unit tests out, install Lower Panel on Water Cooler. Units are now ready for use.
3. Purge air from all water lines by:
• Depressing button or front push bar of cooler/fountain.
• Depressing the button at top of the Bottle Filler and verify water dispenses.
NOTE: Steady stream of water assures all air is removed.
