Page 298550C (Rev. B - 8/10)
LZS8WS*1A, LZSDWS*1A, LZSTL8WS*1A, LZSTLDWS*1A
LZS8WS*2A, LZS8WS*3A, LZSTL8WS*2A, LZSTL8WS*3A
17 7/8
454mm
15
381mm
7
178mm
7
178mm
O
7/16
11mm
MOUNTING HOLES
(6)
3 9/16
90mm
18 13/16
478mm
3 9/16
90mm
17 7/8
454mm
18 13/16
478mm
15
381mm
7
178mm
7
178mm
O
7/16
11mm
MOUNTING HOLES
(6)
Single Rough-In
Fig. 1
Two -Level Rough-In
Fig. 2

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Elkay EZH2O LZS8WS 1A Series and is the answer not in the manual?

Elkay EZH2O LZS8WS 1A Series Specifications

General IconGeneral
Installation TypeWall Mounted
Cooling Capacity8.0 GPH
FilteredYes
MaterialStainless Steel
Bottle Filling StationYes
ADA CompliantYes
Product NameElkay EZH2O LZS8WS 1A Series
CategoryWater Dispenser
Power115V/60Hz
BrandElkay
Cooling Capacity Temperature50°F
Voltage115V
FinishStainless Steel
Refrigeration Capacity8.0 GPH
Bubbler ActivationPush Button
ModelLZS8WS
TypeWater Cooler
Dispenser TypeBottle Filling Station with Water Cooler
CertificationsNSF/ANSI 61, NSF/ANSI 372
Mounting StyleWall Mount (On-Wall)
