2 / 8
TER-9
TC TZ
14.7
9.8
6.6
4.6
3.2
2.3
20
30
40
50
60
70
PRG
OK
+
_
OK
+
_
Prog
OK
Auto
Prog
ter
Prog
options
Prog
language
Prog
Prog
Prog
Prog
ESPAnOL
Prog
Prog
Technical parameters
Supply
Supply terminals:
Supply voltage:
Consumption:
Supply voltage tolerance:
Backup battery type:
Measuring circuit
Measuring terminals:
Temperature range:
Hysteresis (sensitivity):
Diference:
Sensor:
Sensor failure indication:
Accuracy
Measuring accuracy:
Repeat accuracy:
Temperature dependance:
Number of function:
Output
Number of contacts:
Rated current:
Switching capacity:
Switching voltage:
Output indication:
Mechanical life:
Electrical life (AC1):
Time circuit
Real time back-up:
Accuracy:
Minimum interval:
Data stored for:
Program circuit
Number of memory places:
Program:
Data readout:
Other information
Operating temperature:
Storage temperature:
Electrical strength:
Operating position:
Mounting:
Protection degree:
Overvoltage cathegory:
Pollution degree:
Max. cable size (mm
2
):
Dimensions:
Weight:
Standards:
A1 - A2
AC 230 V (AC 50-60 Hz), galvanically isolated or
AC/DC 24 V, not galvanically isolated
max. 4 VA
-15 %; +10 %
CR 2032 (3V)
T1-T1 a T2-T2
-40.. +110 °C
adjustable within range 0.5...5 °C
adjustable 1 .. 50 °C
thermistor NTC 12 kΩ at 25 °C
displayed on LCD *
5 %
< 0.5 °C
< 0.1 % / °C
6
1x switching for each output (AgNi)
8 A / AC1
2000 VA / AC1, 240 W / DC
250 V AC1 / 30 V DC
symbol ON/OFF
1x10
7
1x10
5
up to 3 years
max. ±1s/ day at 23°C
1 min.
min. 10 years
100
daily , weakly, yearly
LCD display, with back light
-10.. +55 °C
-30.. +70 °C
4 kV (supply - output)
any
DIN rail EN 60715
IP40 from front panel / IP20 clips
III.
2
max. 1x 2.5, max. 2x 1.5 /
with sleeve max. 1x 2.5
90 x 35.6 x 64 mm
(230V) 127 g, (24V) 120 g
EN 61812-1; EN 61010-1;
EN 60730-2-9; EN 60730-1; EN 60730-2-7
* ERROR - sensor short circuit
NO SENSOR - interruption sensor
Temperature sensor TC, TZ
Temperature (°C) NTC sensor (kΩ)
Tolerance of sensor NTC 12 kΩ is ± 5% at 25 °C.
Resistance value of sensors based on temperature
Mode precendence
mode precedence
display output mode
ON / OFF
manual control
ON / OFF
holiday mode
ON / OFF
time program
Prog
ter
thermostat
mode with the highest
priority
ter and Time Program can work at the same time on a single channel.
Language settings
language
Language
selection
options
PRG
entrance into programming menu
+
_
browsing in menu
setting of values
+
_
quick shifting during setting of values
OK
entrance into required menu
con rmation
switch. between display
ESC
one level up
a step back
ESC
back to the starting menu
Control description
Device di ers short and long button press. In the manual marked as:
- short button press (<1s)
- long button press (>1s)
After 30s of inactivity (from the last press of any button) will device automatically returns
into starting menu.
In the start screen, press
OK
to toggle between displaying the date or measured
temperature.
