IT500CLOUD 13
ALLOGGIAMENTO NELLA CENTRALE MP500/8
LOCATION IN THE MP500/8 CONTROL PANEL
LOGEMENT DANS LA CENTRALE MP500/8
Alloggiamenti
Dispositivo
C
Espansione filare EP508 o radio ER600 o IT500CLOUD
D
Espansione filare EP508 o IT500CLOUD
Location Device
C Wired expansion EP508 or radio ER600 or IT500CLOUD
D Wired expansion EP508 or IT500CLOUD
Logement
Dispositif
C
Extension filaire EP508 ou radio ER600 ou IT500CLOUD
D
Extension filaire EP508 ou IT500CLOUD
Fondo box centrale MP500/8
Box bottom of the MP500/8 control panel
Fond de la boîte de la centrale MP500/8
Figura 3 - Figure 3 - Figure 3
