What to do if Ellies Battery Charger shows Output Overload?
If the Ellies Battery Charger indicates an output overload, reduce the number of AC loads. You can also try restarting the device, or change the CFA setting interface to ON.
What to do if Ellies Battery Charger has Output Short Circuit?
If the Ellies Battery Charger experiences an output short circuit, carefully check the load connections and clear the fault. Then, restart the device, or change the CFA of setting interface to ON.
How to fix Battery Over Discharge on Ellies Battery Charger?
To address a battery over discharge issue on the Ellies Battery Charger, wait until the battery voltage reaches or exceeds the LVR (low voltage reconnect voltage) point. Alternatively, replace the battery.
Key safety precautions and general guidelines to follow before and during installation.
Specifies required wire gauges and circuit breakers for PV, Utility, and Battery connections.
Explains the necessity and method for establishing a reliable grounding connection for safety.
Covers protections for PV and Utility inputs against voltage, current, and polarity issues.
Details protections for the battery against overcharging and over-discharging.
Covers protections for AC output short circuits, overloads, and device overheating.
Details electrical performance data including voltage, current, power, and efficiency ratings.
Provides mechanical dimensions, enclosure rating, and operating environment parameters.
General| Input Voltage | 230V AC |
|---|---|
| Output Voltage | 24V DC |
| Output Current | 30A |
| Power Rating | 3000VA |
| Cooling | Fan Cooled |
| Operating Temperature | 0°C to 40°C |
| Storage Temperature | -20°C to 60°C |
| Charging Method | 3-stage charging (Bulk, Absorption, Float) |
| Protection | Overload, Short Circuit, Over Temperature |
| Battery Type | Lead Acid (Gel, AGM, Wet) |
| Humidity | 5% to 95% (Non-condensing) |
