Elma Cyclomotion - Front View

Product description
© Elma Schmidbauer GmbH
BA_Cyclomotion_EN_Vers.09.2019
9
3.7 Front view
Fig. 3.7. front view
Operating panel (detailed view see below)
Mechanic disengaging screw
Protecting hood (Cyclomotion pro only)
Knurled screw for fastening the clips
Lock on protecting hood (Cyclomotion pro only)
Clip
Spindle head
A
B
C
D
E
F
G
A
B
C
D
G
E
F
