ELMECO FC3 User Manual

- 24 -
#
CODICI/CODES
DESCRIPTION

1
M0004109-002
RING NUT HORIZONTAL AUGER







2
M0003126-003
RING NUT LEVER COVER PISTON









3
M0003139-001
HANDLE +COVER

6
OR13000117
O-RING 117

9
M0003117-001
OUTLET GASKET



12
M0006134-001
DISPENSING SPOUT







13
M0000106-001
GASKET TRANSPARENT TANK







14
M0000147-001
TRANSPARENT TANK



15
M0005159-001
LOW VOLTAGE CONTACT WIRES KIT



















18
ME005101-001
LED LIGHT

20
VTTC2.9X9.5CR
SCREW TC 2.9X9.5

21
M0005109-001
12V CONTACT FOR TANK
12 
22
M0006129-001
PLASTIC LENS STICKER





24
M0006193
TOP LIGHT

28
M0000107-001
RING NUT VERTICAL PROPELLER







29
M0000108-001
TRANSMISSION SHAFT WITH NUT





30
M0004111-001
VERTICAL AUGER WITH STAINLESS STEEL BUSHING


 Bushing
32
M0004104-002
PINION VERTICAL AUGER








33
M0000104-001
BUSHING TRANSMISSION SHAFT


 Bushing
34
M0000161-002
TRANSMISSION SHAFT WITH SLEEVE








35
A0001104-001
GEAR MOTOR/TRANSMISSION SHAFT PIN
  /    PIN
36
A0000114-001
TRANSMISSION SHAFT GASKET





37
M0005117-004
TERMINAL BOARD COMPLETE





38
M0006103-003
REAR HINGE

39
M0000120-001
M5 SQUARE NUT







40
M0001101-001
SCREW TE 5X12MM

41
M0000105-001
RING NUT SHAFT FASTENING







42
M0002112-007
COMPLETE INOX TANK

43
M0000157-002
THERMOSTAT PROBE COMPLETE







45
M0004105-002
HORIZONTAL AUGER GEAR





46
M0004110-002
HORIZONTAL AUGER WITH PLASTIC BUSHING


 Bushing 
47
M0006116-003
BASE

48
M0006102-003
HINGE HOOK





49
M0006115-003
FRONT HINGE

50
M0006119-001
LOCKING BOLT







107
M0003130-001
OUTLET RESTRICTION



125
M0005139-002
GEAR MOTOR



126
M0004102-002
HORIZONTAL AUGER BUSHING
 Bushing
127
A0000117-001
BOCCOLA CENTRAGGIO MOTORID./ALBERO


 Bushing
128
A0000115-001
VITE TE FLANGIATA M5X20MM

