VII. Configuration Level
Display Parameter Display
"Process" „Set“
ConF Controller configuration 2P h 2-point- or continuous-controller „heating“ (ex works)
2P c 2point-controller or Continuous-controller „cooling“
2Pnc 2point-controller or Continuous-controller „cooling“
with non-linear cooling*)
3P 3-point controller: "heating - off - cooling"
3Pnc 3-point controller: "heating - off - cooling"
cooling mode with non-linear cooling*)
3PSt 3-point-step-controller „on-neutral-off“
*) Cooling action can be pre-selected with either linear or
non-linear cooling response curve ( e.g. for vapour cooling).
Out1 Configuration Output 1 OFF OUT 1 not active
Controller output rEL. Relay (ex works)
biSt. bistable voltage signal
Out2 Configuration Output 2 OFF OUT 2 not active
Controller output or rEL. Relay (ex works)
alarm (A2) output biSt. bistable voltage signal
Out4 Configuration Output 4 OFF Output OUT4 not active
Only version: R1300-2
and version: R1300-3 if ConF= 2Ph:heating, ConF= 2Pc: cooling, ConF= 2Pnc: cooling
if ConF= 3P :heating, ConF= 3Pnc:heating
Co.h0 Control output: 0...20mA / 0...10V
Co.h4 Control output: 4...20mA / 2...10V
if ConF= 3P :cooling, ConF=3Pnc:cooling
Co.c0 Control output: 0...20mA / 0...10V
Co.c4 Control output: 4...20mA / 2...10V
Only version: R1300-3 Pr. 0 Process value output: 0...20mA / 0...10V DC
Pr. 4 Process value output: 4...20mA / 2...10V DC
SP. 0 Analogue setpoint output: 0...20mA / 0...10V DC
SP. 4 Analogue setpoint output: 4...20mA / 2...10V DC
Out5 Configuration Output 5 OFF Output OUT5 not active
Only version: R1300-3
if ConF= 2Ph:heating, ConF= 2Pc: cooling, ConF= 2Pnc: cooling
if ConF= 3P :heating, ConF= 3Pnc:heating
Co.h0 Control output: 0...20mA / 0...10V
Co.h4 Control output: 4...20mA / 2...10V
if ConF= 3P :cooling, ConF=3Pnc:cooling
Co.c0 Control output: 0...20mA / 0...10V
Co.c4 Control output: 4...20mA / 2...10V
Pr. 0 Process value output: 0...20mA / 0...10V DC
Pr. 4 Process value output: 4...20mA / 2...10V DC
SP. 0 Analogue setpoint output: 0...20mA / 0...10V DC
SP. 4 Analogue setpoint output: 4...20mA / 2...10V DC
