BASIC OPERATION
To take a reading the appropriate yellow button is pushed depending on the
measurement required and the reading is taken.
UV= Ultra Violet (µW/lumen or mW/M
2
)
Vis= Visible light (Lux or Foot-candles)
T= Temperature (Centigrade or Fahrenheit)
RH= Humidity (%Relative Humidity)
The unit automatically turns off 20 seconds after the button is released unless a button
is held down for over 3 seconds, this will cause readings to be taken continuously until
a button is pressed again.
If the T and UV buttons are pressed together then all parameters are displayed at the
same time. Hold both the buttons down for over 3 seconds for a continuous readout.
RH & T pressed together shows atmospheric pressure and other information (see
below). This only works with later models (Hardware version greater than 13).
Typical display:
A
B
C
D
E
F
G
56.2
%RH
T: 26.4°C
DP: 17.0°C
13:10
15-06-2012
H L B
A: Current reading
B: Units of measurement
C: Subsidiary reading (Current temperature)
D: Subsidiary reading (DP = Dew Point)
E: Current time (24 hour clock)
F: Current date
