Elson EUV10 - Technical Specifications; Electrical Rating and Performance

3
2.0 TECHNICAL SPECIFICATIONS
Electrical rating ............................................. 220-240V~ 50Hz 2kW
Temperature range ....................................... 12 to 72°C
Capacities ......................................................10 or 15 litres
Weight (empty) ..............................................10 litre - 6.5kg
.............................................. 15 litre - 7.5kg
Weight (full) ................................................... 10 litre - 16.5kg
................................................... 15 litre - 22.5kg
Maximum working pressure............................0.6MPa (6 bar)
Pressure Relief Valve .....................................0.6MPa (6 bar)
Ingress protection ...........................................IPX2
B
F
D
EC
G
H
A
FIG.01: INSTALLATION DIMENSIONS
MODEL A B C D E F G H
10 litre 415 265 264 73 140 100 380 102
15 litre 445 295 296 93 140 100 420 102
The heater can be used to supply multiple hot water outlets via conventional
taps. It is not recommended for supplying a shower.
Individual site demands should be considered when choosing capacity and
the number of outlets to be served.
10 litre - 1 to 2 hand basins
15 litre - 2 to 3 basins or 1 kitchen sink + 1 hand basin
