■󰼿FM/AM AUTO STOP LEVEL ADJUSTMENT
FM Signal Generator .. .. .. .. Connect to FM ANT Jack (FM IN) through the dummy.
AM Signal Generator .. .. .. .. Connect to AM ANT. Coil the through the Loop anten na.
BANDStep
Adjustment
TUNED Display ON
TUNED Display OFF
Signal Generator Adjust for
AM
FM
1
2
1
2
999§Õ 82dB
999§Õ 81dB
100.10§Ö 25dB
100.10§Ö 24dB
TUNED Display ON
TUNED Display OFF
SVR03
SVR03
SVR01
SVR01
- 4 -
AM SG
AM LOOP ANTENNA
AC EVM OSCILLOSOPE
KHz
OUT
OUTPUT
60 cm
FM SG
75 ohm
AC EVM OSCILLOSOPE
MHz
OUT
OUTPUT
FM ANT.
