Eltax Voyager BT12 User Manual

FM Antenna
LED Power
12V Battery IN
External 12V battery
input (not provided)
Volume
Master volume
Bass
To adjust bass level
Treble
To adjust treble level
Echo
To adjust micro echo depth
Micro Volume
Guitar Volume
Micro 1
Wired micro input
Micro 2
Wired micro input
Guitar
Guitar wire input
Micro Antenna
Display screen
Playing functions
(1)
SD/MMC Card
AUX input
Audio output
To connect other Voyager
Battery LED
indicator
(3)
AC input
Power adaptor input
Power switch
DC : to use with battery
AC : to use with power
adaptor
USB input
IR receiver
Voyager BT15
(3)
LED indicator :
Charge Full (Green light) : battery is full
Low (Red light) : battery is low and needs to be charged
Echo
To adjust micro echo depth
(1)
PLAYING FUNCTIONS
Play/pause
Stop
Press and release to select the previous song / Press and hold for more than 3 seconds for VOL- function
Press and release to select the next song / Press and hold for more than 3 seconds for VOL+ function
MODE : Select and switch between BT, AUX and FM inputs (note : USB and SD are automatically detected).

Eltax Voyager BT12 Specifications
