ELTEX ESR-1511 - 19.2 FXS;FXO ports configuration algorithm

ESR series service routers.ESR-Series. User manual
634
Step Description Command Keys
9 Configure a registration server
address.
esr(config-voip-sip-proxy)#
ip address registration-
server <IP>
<IP> – registration server IP address.
10 Configure a registration server
port.
esr(config-voip-sip-proxy)#
ip portregistration-server
<PORT>
<PORT> – number of registration server
UDP port, takes values of [1..65535]. If
standard 5060 port is used,there is no
need to specify it.
11 Specify SIP domain in which the
device is located.
esr(config-sip-profile)# sip-
domain address <ADDRESS>
<ADDRESS> – SIP domain in which the
device is located, set by ipv4 address or
domain name.
12 Enable the use of SIP domain
when registering.
esr(config-sip-profile)# sip-
domain registration enable
13 Configure a SIP profile. esr(config)# sip profile
<NUM>
<NUM> – SIP profile number, set in the
form of a digit from 1 to 5.
14 Assign a dial plan to the current
SIP profile.
esr(config-sip-profile)#
dialplan pattern <DNAME>
<DNAME> – name of the dial plan, set by
the string of up to 31 characters.
15 Enable SIP profile. esr(config-sip-profile)#
enable
19.2 FXS/FXO ports configuration algorithm
Step Description Command Keys
1 Switch to the FXO/FXS ports
configuration mode.
esr(config)# interface voice-
port <NUM>
<NUM> – port number, takes values of
[1..4].
2 Assign a subscriber number
reserved for a telephone port.
esr(config-voice-port-fxs)#
sip user phone <PHONE>
<PHONE> – subscriber number reserved
for a telephone port, set by the string of
up to 50 characters.
3 Assign the user name matched
with the port.
esr-12v(config-voice-port-
fxs)# sip user display-name
<LOGIN>
<LOGIN> – user name displayed in the
Display-Name field, set by the string of up
to 31 characters.
4 Select SIP profile for a certain port. esr(config-voice-port-fxs)#
profile sip <PROFILE>
<PROFILE> – SIP profile number, set in
the form of a digit from 1 to 5.
