eltherm Ex-TC It Series User Manual

1
2
3
5
2
4
3
5
7
www.eltherm.com
7
www.eltherm.com
Ex-TC/M-It
POS Art.No. TYPE
Tighten-
ing
torque
[Nm]
Clamping
range
2 2576020058
Screw connection
M20x1.5
2,30 4-13
3 2572580009
Reduction
M25x1.5/M20x1.5
3,00
4 2576025050
Screw connection
M25x1.5
3,00 2x7,2-8
5 2576025092
Screw connection
M25x1.5
5,00 9-17
SCOPE OF DELIVERY
Ex-TC/A-It & Ex-TC/AL
POS Art.No. TYPE
Tighten-
ing
torque
[Nm]
Clamping
range
1 2576020056
Plug
M20x1.5
2,00
2 2576020058
Screw connection
M20x1.5
2,30 4-13
3 2572580009
Reduction
M25x1.5/M20x1.5
3,00
5 2576025092
Screw connection
M25x1.5
5,00 9-17
The connection sets required for
safely and properly connecting the eltherm ELSR
heating cables are not included with delivery.
NOTE
i
INCOMING GOODS
Check the controller and accessories when the goods are re-
ceived and compare the data on the type plate with the data
on the delivery slip to make certain the correct materials have
been delivered.
STORAGE
Store in a dry environment at an ambient temperature of 0°C
to 50°C.
the applicable regulations. This manual is intended for
that group of persons and contains all important infor-
mation required for working safely with Ex-TC control
devices.
• The manual must be retained with the system docu-
mentation
for later use and must be kept and made available
throughout the entire service life of the product.
• Mounting of the Ex-TC/...It should only be carried
out by persons trained in working with Ex devices.
• Strict compliance with the applicable safety
requirements in areas subject to explosion hazard
is a precondition for the safety of persons, systems
and devices.
• The persons tasked with planning, installation and
maintenance have a special responsibility and
must therefore be familiar with the exact details of
SAFETY INSTRUCTIONS
ATTENTION
ALARM
POWER
SUPPLY
or
BUS
POWER
SUPPLY
