ENGLISH
CROSS-CUT MITRE SAW PS274/PS274E
Congratulations!
You have chosen an Elu product. Years of experience, thorough product
development and innovation make Elu one of the most reliable partners for
professional users.
Table of contents
Technical data en - 1
EC-Declaration of conformity en - 1
Safety instructions en - 2
Package contents en - 3
Description en - 3
Electrical safety en - 3
Mains plug replacement (U.K. & Ireland only) en - 3
Using an extension cable en - 3
Assembly en - 4
Adjustment en - 4
Instructions for use en - 5
Maintenance en - 7
Guarantee en - 7
Technical data
PS274 PS274E
Voltage V 230 230
(U.K. & Ireland only) V 230/115 230/115
Motor power (input) W 1,200 1,600
Motor power (output) W 800 1,100
Blade diameter mm 216 216
Blade bore mm 30 30
Max. blade speed min
-1
6,700 2,500-5,000
Mitre (max. positions) left and right 48° 48°
Bevel (max. positions) left 48° 48°
Compound mitre bevel 45° 45°
mitre 45° 45°
Capacities
cross-cut 90° mm 60 x 270 60 x 270
mitre 45° mm 60 x 190 60 x 190
mitre 48° mm 60 x 180 60 x 180
bevel 45° mm 48 x 270 48 x 270
bevel 48° mm 44 x 270 44 x 270
Overall dimensions mm 460 x 560 x 430 460 x 560 x 430
Weight kg 15.5 16
Fuses:
Europe 230 V tools 10 Amperes, mains
U.K. & Ireland 230 V tools 13 Amperes, in plugs
The following symbols are used throughout this manual:
Denotes risk of personal injury, loss of life or damage to the
tool in case of non-observance of the instructions in this
manual.
Denotes risk of electric shock.
Sharp edges.
EC-Declaration of conformity
PS274/PS274E
Elu declares that these Power Tools have been designed in compliance
with: 89/392/EEC, 89/336/EEC, 73/23/EEC, EN 50144, EN 55104,
EN 55014, EN 61000-3-2 & EN 61000-3-3.
For more information, please contact Elu at the address below,
or refer to the back of the manual.
Level of sound pressure according to 86/188/EEC & 89/392/EEC,
measured according to EN 50144:
PS274 PS274E
L
pA
(sound pressure) dB(A)* 89.7 89.7
L
WA
(acoustic power) dB(A) 97.7 97.7
* at the operator’s ear
Take appropriate measures for the protection of hearing if the
sound pressure of 85 dB(A) is exceeded.
Weighted root mean square acceleration value according to EN 50144:
PS274 PS274E
<2.5 m/s
2
<2.5 m/s
2
TÜV Rheinland
Sicherheit und Umweltschutz GmbH
Am Grauen Stein
D-51105 Köln
Germany
Cert. No.
BM 9410802 01
Director Engineering and Product Development
Horst Großmann
Elu International, Richard-Klinger-Straße 40,
D-65510, Idstein, Germany
