16 en - 1
ENGLISH
SLIDING COMPOUND MITRE SAW PS374
Congratulations!
You have chosen an Elu Power Tool. Years of experience, thorough
product development and innovation make Elu one of the most reliable
partners for professional Power Tool users.
Table of contents
Technical data en - 1
EC-Declaration of conformity en - 1
Safety instructions en - 2
Electrical safety en - 3
Mains plug replacement (U.K. & Ireland only) en - 3
Using an extension cable en - 3
Unpacking en - 3
Description en - 3
Assembly en - 4
Adjustment en - 4
Instructions for use en - 5
Transport en - 7
Maintenance en - 7
Guarantee en - 8
Technical data
PS374
Voltage V 230
(U.K. & Ireland only) V 230/115
Power input W 1,600
Blade diameter mm 305
Blade bore mm 30
Max. blade speed min
-1
4,000
Mitre (max. positions) right 60°
left 50°
Bevel (max. positions) right 48°
left 48°
Capacity of cut (height x width)
At 0° mitre, 0° bevel mm 103 x 305
At 45° mitre, 0° bevel mm 103 x 216
At 0° mitre, 45° left bevel mm 81 x 305
At 0° mitre, 45° right bevel mm 43 x 305
Weight kg 27.0
Fuses:
Europe 230 V tools 10 Amperes, mains
U.K. & Ireland 230 V tools 13 Amperes, in plugs
The following symbols are used throughout this manual:
Denotes risk of personal injury, loss of life or damage to the
tool in case of non-observance of the instructions in this
manual.
Denotes risk of electric shock.
Sharp edges.
EC-Declaration of conformity
PS374
Elu declares that these Power Tools have been designed in compliance
with: 89/392/EEC, 89/336/EEC, 73/23/EEC, EN 50144, EN 55104,
EN 55014, EN 61000-3-2 & EN 61000-3-3.
For more information, please contact Elu at the address below or refer to
the back of the manual.
Level of sound pressure according to 86/188/EEC & 89/392/EEC,
measured according to DIN 45635:
PS374
L
pA
(sound pressure) dB(A)* 89
L
WA
(acoustic power) dB(A) 102
* at the operator’s ear
Take appropriate measures for the protection of hearing if the
sound pressure of 85 dB(A) is exceeded.
Weighted root mean square acceleration value according to DIN 45675:
PS374
< 2.5 m/s
2
TÜV Rheinland
Sicherheit und Umweltschutz GmbH
Am Grauen Stein
D-51105 Köln
Germany
Cert. No.
S 9710929 01
Director Engineering and Product Development
Horst Großmann
Elu International, Richard-Klinger-Straße 40,
D-65510, Idstein, Germany
