5
POWER SUPPLY TERMINALS SUGGESTED CONDUCTOR COLOUR
(Ref. Cable type 61/001)
1: Interphone receiver SKY BLUE
2: Interphone microphone WHITE
3: Common interphone line PINK
- : Negative terminal of monitor supply voltage BLACK SECT. 1mm
+: Positive terminal of 18V D.C. 0.8A monitor supply RED SECT. 1mm
S: Control of lock relay BROWN
M: Block of coaxial cable shield
V1-V2: Block of video signal (on coax cable) COAXIAL CABLE
6: Common interphone line for speech unit PINK
7: Speech unit microphone WHITE
8: Speech unit loudspeaker SKY BLUE
+T: 13V D.C. 0.3A camera supply voltage ORANGE
- : Negative line for camera supply voltage BLACK SECT. 1mm
AM: Short-circuited to negative line, blocks monitor activation
0: 0V (with reference to terminal 16) BROWN
15: 15V rectified voltage (selector in “A” position).or 250mA RED SECT. 1mm
alternated (selector in “B” position on continuous
operation)
S1: Wiring to electric lock BLUE SECT. 1mm
C1: Speech unit electronic call GREEN
C2: Electronic call outside apartment landing call WHITE/GREEN
CONNECTIONS TO
MONITORS +
INTERPHONES
CONNECTION TO
CAMERA ENTRANCE
PANEL
